WOSSNER 72.5mm FORGED PISTON KIT KTM 300 SX/EXC/MXC 1996-2003

Piston kit 72.50mm Bore 72.43 Wossner 8017D050 (+0.50)

KTM
EGS300 1996 - 2003,
EXC300 1996 - 2003,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W712+050.WO
Wossner Piston KTM EGS300 72.50 mm Bore (PN# 8017D050)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB7250 X 2
Rod P/N P2024

Display (cm3) 297
Hub stroke (mm) 72.00
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 26.70
Theorectical weight (G)

�
