WOSSNER 96mm PISTON KIT B, KAWASAKI KX450F 2015

Wossner forged piston kit with a 96.01mm bore, designed for the 2015 Kawasaki KX450F. Engineered for strength and efficient heat transfer, the elliptical design ensures uniform bearing surface expansion, reducing localized pressure and preventing piston collapse under heat expansion. Manufactured in Germany for high performance and durability.

Features

• Forged construction for increased strength and reliability
• Optimized heat transfer for efficient combustion
• Elliptical design for uniform bearing surface and even thrust load distribution
• Manufactured in Germany

Specifications

• Bore Size: 96.01mm
• Clearance: 0.05mm
• Compression Ratio (Wossner): OEM
• OEM Compression Ratio: 12.80:1
• Dome Volume: +0.90 cm³
• Compression Height: 23.70mm
• Stroke: 62.10mm
• Displacement: 449 cm³
• Theoretical Weight: 259.00g

Cross-Reference OEM Part Numbers

• Wossner Part No.: 8920DB

Vehicle Fitments

• Kawasaki KX450F (2015)
