STARTER MOTOR YFM50 80 100 55X-81800-50-00, 65X-81880-50-
STARTER MOTOR YFM50 80 100 55X-81800-50-00, 65X-81880-50-
Couldn't load pickup availability
YAMAHA
YFM50 Raptor 2004-2008,
YFM80 Badger 1986-88 / 1982-2001,
YFM80 Grizzly 2005-2008,
YFM80 Raptor 2002-2008,
YFM100 Champ 1987-1991,
YFM100 Moto-4 1985-1989,
| Technical specifications | |
| Tension (voltage) | 12 [V] |
| # dientes (#gear teeth) | 12 |
| Diametro engranaje (gear diameter) | 26 [mm] |
| Sentido de giro (spin) | IZQUIERDA (LEFT) |
| dze products that apply to | |||||
| Brand | Model | Version | Displacement | Year | OEM |
| Yamaha | YFM | Badger | 80 | from 1985 to 2001 | 55X-81800-51 |
| Yamaha | YFM | Champ | 100 | from 1987 to 1991 | 55X-81800-51 |
| Yamaha | YFM | Grizzly | 80 | from 2005 to 2008 | 55X-81800-51 |
| Yamaha | YFM | Raptor | 50 | from 2004 to 2008 | 55X-81800-51 |
| Yamaha | YFM | Raptor | 80 | from 2002 to 2008 | 55X-81800-51 |
- Meets or exceeds OEM quality.
- Direct oem replacement.
- All products are factory tested for 100% reliability at point of sale.
- Designed to handle increased power loads.
- DZE Racing products are a high quality replacement part and carries our guarantee of your satisfaction.
- Please check the image and connection plugs before ordering to avoid mistakes.
- Note. No Returns on Electrical Parts.
12-Volt; CW; 9-Spline
Part No. 19-111.AR
Cross reference numbers ONLY.
55X-81800-50-00, 55X-81800-51-00, 65X-81880-50-00, SND0051, LESTER 18340, DENSO 128000-1990, AT-01075, 410-52039
SND0051 � � � ARROWHEAD � � �
ND128000-1990 � � � ARROWHEAD (OEM) � � �
410-52039 � � � J & N � � �
18340 � � � LESTER � � �
190-533 � � � PIC � � �
610-001 � � � BARSANCO � � �
22-18340 � � � BBB SMALL MOTOR � � �
111928 � � � CARGO � � �
128000-1990 � � � DENSO � � �
MS-819 � � � DIXIE � � �
246-06118 � � � DIXIE NEW � � �
YA-101N � � � EMS � � �
MEY080 � � � MES MOTORCYCLE & MARINE � � �
MEY100 � � � MES MOTORCYCLE & MARINE � � �
57-2771 � � � MINNPAR � � �
P339N � � � MPA SMALL MOTOR � � �
RN18340 � � � NAPA SMALL MOTOR � � �
ST-18340 � � � RCP � � �
RS41269 � � � REMY SMALL MOTOR � � �
YA-101 � � � STOCKERS STARTERS � � �
495708 � � � TUCKER ROCKY � � �
49-5708 � � � TUCKER ROCKY � � �
2-2187 � � � WAI � � �
91-29-5418 � � � WILSON � � �
71-29-18340 � � � WILSON SMALL ENGINE � � �
STR70030 � � � WOOD AUTO � � �
55X-81800-50-00 � � � YAMAHA � � �
55X-81800-51-00 � � � YAMAHA � � �
65X-81880-50-00 � � � YAMAHA
Yamaha YFM 100 Champ 1987, 1988, 1989, 1990, 1991
�
Yamaha YFM 100 Champ 1987, 1988, 1989, 1990, 1991
�
Yamaha YFM 100 Moto-4 1985, 1986, 1987, 1988, 1989
�
Yamaha YFM 50 Raptor 2004, 2005, 2006, 2007, 2008
�
Yamaha YFM 50 Raptor 2004, 2005, 2006, 2007, 2008
�
Yamaha YFM 80 Badger 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001
�
Yamaha YFM 80 Badger 1986, 1987, 1988, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001
�
Yamaha YFM 80 Grizzly 2005, 2006, 2007, 2008
�
Yamaha YFM 80 Grizzly 2005, 2006, 2007, 2008
�
Yamaha YFM 80 Raptor 2002, 2003, 2004, 2005, 2006, 2007, 2008
�
Yamaha YFM 80 Raptor 2002, 2003, 2004, 2005, 2006, 2007, 2008
Share
SKU:REF 19-111.AR
